    Ecoographix Automatic Slitting And Rewinding Machine For Thermal Paper

    Slitting And Rewinding Machine For Thermal Paper

    EcooGraphix T-1200C is used for making all kinds of thermal paper rolls, including fax paper roll, ECG paper roll, medical record paper roll, POS roll, ATM roll, cash register paper roll, etc.


    Features
    1.SIEMENS PLC control system and touch screen, all the parameters are displayed on the monitor. Just setup the roll diameter, material thickness, initial tension, the machine runs automatically.
    2.Shaftless hydraulic loading system, Max. load capacity is 3 tons.
    3.20Kg/m2 electromagnetic brake for unwinding tension control.
    4.CNC processed & heat-treatment foothold wall panel, no deformation.
    5.Unwinding section equips with direction adjustable balancing roller, ensures roller itself keeping tight touch with whole web.
    6.Dynamic / static balancing transmission rollers.
    7.The upper circular knives are fixed by screws, and the lower circular knives are fixed by aluminum spacer, cutting precision could be guaranteed.
    8.Automatic tucker tucks the tail, convenient for quickly trigger rewinding.
    9.Load cell sensor & automatic tension controller ensures constant tension.
    10.Automatic meter counter, when reaches preset length, machine stops automatically.
    11.Overlapping problem could be avoided with banana roller.
    12.Equipped with emergency switch.
    13.CCD digital camera sensor or photocell for web guiding.


    Specification

    Model TypeEcoo-1200C
    Max. Unwinding Width1200mm
    Max. Unwinding Diameter1200mm
    Max. Rewinding Diameter310mm
    Min. Slitting Width25mm
    Max. Machine Speed210m/min
    Main Power3.7Kw
    Total Power6kw
    Unwinding ShaftHydraulic Shaftless Unwinder to fix 3'' 6'' core
    Rewinding Shaft0.5'', 1'' or as your request
    Weight4000Kgs
    Overall Dimension3100*2100*1900mm

    Main Machine Parts

    1. Unwinding Section
    Hydraulic Shaftless Unwinder to fix 3'' 6'' core which more easier to loading material
    Electromagnetic Brake from Taiwan
    Fully automatic tension controller
    One set of Photocell to tracking the precision

    2. Slitting Section
    Disc cutter
    Cutter with adjustable and movable blade base.
    Meter counter
    Banana Roller which can avoid overlapping problem completely.

    3. Rewinding Section
    0.5",1" or as your request
    Surface Rewinding technology, it adopts vertical method to press the rewinding roll
    Electromagnetic Clutch from Taiwan
    Surface Rewinding technology
    Automatic cutting & gluing unit

    4. Controlling Section
    Siemens PLC & HMI from Germany
    All the parameters are displayed on the monitor
    Low voltage electrical appliances all from Germany brand

    5. Trimmed Waste
    It adopts air blower to blow waste material off, the air blower power is 0.75kw.
    Air blower pipe is more wear-resisting.

    6.Optional
    Safety guard for the slitting device.
    Emergency Switches on the 4 corner of machine.
    Wrapping Line




    Packages
