    EcooGraphix 22pcs/Min Automatic Double Guide Stripping Machine For Packaging

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : Ecoo QF Series
    Certification : ISO9000, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 2000 Sets/Year
    • Product Details
    • Company Profile

    EcooGraphix 22pcs/Min Automatic Double Guide Stripping Machine For Packaging

    Automatic Double Guide Stripping Machine For Packaging



    Introduction
    This system revolutionizes manual labor, enhancing both product quality and enterprise profitability.
    It incorporates advanced components including a servo motor, Taiwan double guide rail, and ball screw, ensuring precision levels of less than 0.02mm.
    Equipped with the latest hydraulic system featuring an inserted motor and an oil temperature cooling fan (3.75kw power), it maintains constant and substantial working pressure.
    The entire machine is outfitted with PLC technology and operated via a user-friendly touchscreen interface, ensuring safety and ease of operation.

    Features
    Tailored for post-die-cutting strip processing, this series of products dramatically reduces labor requirements while elevating product quality and enhancing company efficiency.
    Specification


    ModelQF 680QF 920QF 1080
    Max sheet size(x)x(y)mm680x460920x6801080x780
    Max paper pile height(mm)100100100
    Min paper pile height(mm)404040
    Min sheet size(x)x(y)mm400x300550x400650x450
    Bench height(mm)850850850
    Max Take off the paper(mm)230x230320x320360x360
    Min Take off the paper(mm)30x3030x3030x30
    Fastest Take off the paper(pcs/min)15-2215-2215-22
    Max Force(bar)707070
    Air consumption(L/min)222
    Power4.2kw/n 380V4.2kw/n 380V4.2kw/n 380V
    Net weight1.5T1.9T2.3T
    Package dimension(mm)2100x1500x22002600x1950x22503000x2150x2200
    Gross weight1.8T2.2T2.6T



    Producing And Packing




    More Details




    FAQ



    1. What are your main products?
    We Ecoographix are a specialized supplier of printing machines and consumables. We cover both digital printing and offset printing, including prepress, pressroom, and post-press, focusing on packaging printing and book printing.
    We have hundreds of users all over the world. We bring forward top quality Chinese printing products to meet diversified printing requirements.


    2. Where is your factory?
    Our sales office is in Hangzhou, one hour by train away from Shanghai. Our factories are in Shanghai, Wenzhou, Suzhou, and Nanyang.

    3. What is your warranty?
    One year for machine and printing head if use our ink. One year for the machine only if do not use our ink.

    4. What is the Lead Time?
    Usually 30 days, and we will try our best to meet your demands.

    5. What about the Installation and after-sales technician support?
    Our engineer can help with the installation and provide the necessary training. The buyer should take the round airplane tickets and service charge
    and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
