    Automatic Coating Machine For Superior UV Spot And Overall Varnish Coatings

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : Ecoo SD-1060
    Certification : CE, ISO900
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 Sets Per Year
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Automatic Coating Machine For Superior UV Spot And Overall Varnish Coatings

    UV Coating Machine model: Ecoo-SD-1060


    The High-Speed UV Spot and Overall Coating machine operates at a maximum speed of 9000 sheets per hour using an upper-swaygripper-pass-sheet method. Its UV curing system is equipped with a Teflon conveying belt which ensures higher speed, precise orientation, higher efficiency in UV curing, and lower power consumption. With this machine, you can achieve high-speed production and quality UV coating.


    By using a UV coater and a Teflon belt, we can ensure that sheets are treated without causing damage or deformation to the grippers. This prevents any potential maintenance issues and allows for easy upkeep. Plus, we can rest easy knowing that high temperatures from UV light won't cause any harm. All in all, this solution makes for a smoother and more efficient process.


    Automatic Coating Machine For Superior UV Spot And Overall Varnish Coatings



    Key Features

    1. High-Speed Feeder:
    Equipped with four suction cups and four forwarding suction cups, our feeder ensures smooth and efficient sheet feeding.
    2. Sheet Transferring Unit:
    Our upper swing sheet transferring method guarantees precise and seamless transfer of sheets at high speed to the pressure cylinder.
    3. Varnish Supply
    Enhanced Varnish Delivery SystemOur advanced varnish delivery system is equipped with steel and rubber rollers, along with a metering roller that allows for easy control over varnish consumption and volume. Additionally, our innovative doctor blade design ensures consistent and precise application of the varnish, meeting the demands of your products. (Varnish consumption and volume can be determined by the LPI of the ceramic anilox roller.) With this system, you can operate smoothly and efficiently without any hassle.
    4. Transferring Unit
    The gripper transfers sheets from the pressure cylinder and the air volume blowing function ensures smooth and scratch-free transfer.

    5. Conveying Unit
    The upper and lower conveyor belts gently curve thin sheets for smooth delivery without any surface damage.
    6. Sheet Delivery
    The Sheet Delivery system is designed to make sheet pile delivery effortless and efficient. It uses an automatic pneumatic patting mechanism that is controlled by a photoelectric detecting sensor to ensure that sheets are stacked neatly. Additionally, the electronic control allows for the safe and quick retrieval of sheet samples for inspection. With this system in place, sheet delivery is sure to be smooth and hassle-free.


    Specification


    ModelEcoo SD-1060
    Max. sheet size730x1060mm
    Min. sheet size310X406mm
    Max. coating size720x1040mm
    Sheet thickness80-500gsm
    Coating registration accuracy±0.2mm
    Production speed9000sheets/hour
    Weight8T
    Dimension10460x2725x1930mm
    Power44KW
    Remark: Production speed depends on sheet weight, size, and quality


    Machine Spare Parts List
    No.DescriptionSpecificationQtyRemark
    1Rubber RollerΦ165.3×11181PCThe ceramic roller
    is not equipped.
    2Doctor Blade0.15*50*11501PC
    3Floor Pad Plate12PCS
    4Chain Link5/8"1PCS
    5Chain Link1/2"1PCS
    6Chain Link3/4"1PCS
    7Tool Box1PCS
    8Inner Hexagon Spanner1.5,2,2.5,3,4,5,6,8,101SET
    9Spanner12"1PCS
    10Screw Driver1PCS
    11Screw Driver1PCS
    12Fixing Spanner5.5-7,8-10-9-11,12-14,13- 16,14-17,17-19,22-241SET
    13Wooden Piece4PCS
    14Grease Port (Straight)M6x15PCS
    15Grease Pipe Jointer (Straight)M6x1xΦ65PCS
    16Grease Pipe Jointer ( curve)M6x1xΦ65PCS
    17ScrewM10x8010PCS
    18Operation Manual1SET
    19User Manual to Inverter1SET
    20Pump Instruction ManualAs per supplier1SET


    Producing And Packaging




    FAQ


    1. What is your warranty?
    Normally 1 year.

    2. What is the Lead Time?
    Usually 45 days, and we will try our best to meet your demands.

    3. What about the Installation and after-sales technician support?
    Our engineer can help with the installation and provide the necessary training. The buyer should take the round airplane tickets and service charge and the local accommodation cost. If you have any problems or questions, we will be at your disposal 7x24 hours.
