Small Size Laminating Machine With Trimming Cutter

∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡

→→→ Automatic Flute Laminator Features

1. Intelligent temperature control, thermally conductive inner steel reel, infrared internal heating.

2. Electric adjustment of single-sided reverse curl function. Electric adjustment of single-sided reverse curl function.

3. Frequency converter speed control, 400W gearbox decelerating motor.

4. Manual pump hydraulic control system, shockproof pressure display gauge.

5. Synchronous conveyor belt automatically feeds paper, and the finished product is automatically broken.

6. Equipped with trimming cutter and dotted tooth cutter.

7. Equipped with an inching foot switch to facilitate film channeling.

8. The diameter of the steel roller is 200mm, and the diameter of the lower rubber roller is 150mm.

9. The rubber roller is made of imported non-sticky high temperature resistant silicone rubber.

∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡

→→→ Specifications

Laminating Machine

Model
S-720A

Max. Laminating Width
720mm

Maximum thickness
2/7mm(according to custom needs)

Laminating Speed
20-25m/min

Roller Diameter
200/150mm

Max. Heating Temperature
160ºC

Preheat time
15-20 minutes

Heating Mode
Infrared heating

Heating Power
3900W/5400W

Power Supply
AC100, 110, 220-240V / 50,60 Hz

Motor Power
400W

Weight
Net: 480kgs, Gross: 550kgs

​

​

∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡

→→→ Producing And Packaging

From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.

∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡ ∧ ≡ ∨ ≡
