    Automatic Packaging Grooving Machine High Speed

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : ECOO 1200B
    Certification : ISO9000, CE
    Price : Negotiable
    Payment Terms : L/C, , T/T
    Supply Ability : 500 Sets/Year
    • Product Details
    • Company Profile

    Automatic Packaging Grooving Machine High Speed

    Automatic Packaging Grooving Machine Of High Speed


    1. Slotting effect: no hairy edge, no dust, low noise;
    2. Tool durability: equipped with special grinder, easy and fast operation;
    3. Environmental protection and energy saving: the total power consumption of the main machine is 2.2 kw, and the whole consumption under slotting can be recovered. (Recycling scrap income can reduce electricity charges and props loss);
    4. The slotting angle can be adjusted: the machine has an angle adjusting device, which can adjust itself on the machine (80-140 degrees) without changing the knife at different angles.
    5. Thickness need not be adjusted: material slotting with different thicknesses need not be adjusted by machine, so it is convenient and fast to use.
    6. High grooving accuracy: A new type of conveying mechanism is used to press the material needed to groove flat on the plane of large drum (diameter 60 cm) through belt, so as to ensure that the grooving position is accurate and without deviation.

    Advantages

    1. Slotting effect: no hairy edge, no dust, low noise;
    2. Tool durability: equipped with special grinder, easy and fast operation;
    3. Environmental protection and energy saving: the total power consumption of the main machine is 2.2 kw, and the whole consumption under slotting can be recovered. (Recycling scrap income can reduce electricity charges and props loss);
    4. The slotting angle can be adjusted: the machine has an angle adjusting device, which can adjust itself on the machine (80-140 degrees) without changing the knife at different angles.
    5. Thickness need not be adjusted: material slotting with different thicknesses need not be adjusted by machine, so it is convenient and fast to use.
    6. High grooving accuracy: A new type of conveying mechanism is used to press the material needed to groove flat on the plane of large drum (diameter 60 cm) through belt, so as to ensure that the grooving position is accurate and without deviation.
    Automatic Packaging Grooving Machine High Speed
    Specification


    Automatic High Speed Grooving machine
    ModelEcoo-1200B
    Quantity of groove at a time8 slots
    Working speed35m/min
    Max size1000*600mm
    Min size140*120mm
    Carton paper thickness500-800 g/m²
    Cardboard thickness0.8-4mm
    Motor power2kw/380v 3 phase
    Machine dimensionL2050*W1520*H1350mm
    Machine weight1250kg


    Producing And Packaging







    FAQ


    1. Payment term?
    Down payment 30% of the total payment shall be made by T/T once order is confirmed and the balance shall be paid by T/T before delivery.

    2. Installation and after service?
    Conditional and prior to mutual agreement between the seller and the buyer.

    3. Warranty?
    12 months from the date of arrival at the port of destination. Damages caused by faulty operation do not fall under warranty wear and tears parts are not under warranty.

    4. Package?
    Seaworthy packaging (vacuum packed with aluminum foil in wooden cases).
