    Intelligent High Speed Multi Axis Cutting Machine For Package

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : ECOO-1316
    Certification : ISO9000, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 2000 Sets/Year
    • Product Details
    • Company Profile

    Intelligent High Speed Multi Axis Cutting Machine For Package

    Ecoo Intelligent Cutting Machine For Packaging



    Control system
    Equipped with the advanced multi-axis high-speed motion control system with independent intellectual property rights, the system upgrade and maintenance are not controlled by the third party, the late maintenance is convenient, high reliability, low cost, because the right of control is in hand, it can be convenient for users to customize special procedures for personalized needs and remote upgrade;

    Positioning function
    Equipped with camera and laser. Realize precise positioning of various materials, with high precision and errors.

    Safety protection
    The beam working area is equipped with infrared blocking technology to ensure the safety of users.
    Specification


    ModelECOO-1316
    Cutting size1300*1600mm
    Cutting materialsVarious corrugated board, plastic corrugated board, Yellow cardboard, red cardboard, white cardboard, gray cardboard, PVC board, Foam board, EVA, KT board, sticker, gasket, etc
    StandardOscillating tool, creasing wheel,pen,drag knife, V cut knife,cursor, milling cut knife
    Cutting thickness≤50mm(according to different materials)
    Speed0-1200 mm/s
    Fixing MethodVacuum suction
    Repeat precision≤0.01mm
    SoftwareIndependent software
    InterfaceEthernet port
    Buffer memoryfast transmission for multi-page large file at one time
    Control paneltouch screen
    Driving systemIntelligent digital control servo system
    Voltage/PowerAC220±V10%,50/60HZ
    Command modeHP-GL/GP-GL

    Producing And Packing






    More Details




    FAQ



    1. What are your main products?
    We Ecoographix is a specialized supplier of printing machines and consumables. We cover both digital printing and offset printing, including prepress, pressroom and post press, focusing on packaging printing and book printing.
    We have hundreds of users all over the world. We bring forward top quality of Chinese printing products to meet diversified printing requirements.


    2. Where is your factory?
    Our sale office is in Hangzhou, one hour by train away from Shanghai. Our factories are in Shanghai, Wenzhou, Suzhou and Nanyang.

    3. What is your warranty?
    One year for machine and printing head if use our ink. One year for machine only if do not use our ink.

    4. What is the Lead Time?
    Usually 30 days, and we will try our best to meet your demands.

    5. What about the Installation and after-sales technician support?
    Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge
    and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
