    Cardboard Automatic Foil Stamping Die Cutting Machine 2500s/H

    Ask Lasest Price
    Brand Name : Ecoographix
    Model Number : TDS 750 L
    Certification : ISO9000, ISO20001, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 600 SET PER YEAR
    Delivery Time : 65 DAYS
    • Product Details
    • Company Profile

    Cardboard Automatic Foil Stamping Die Cutting Machine 2500s/H


    Brief introcution



    TDS750L cardboard die cutting machine is designed for the hot stamping, die cutting, pressing convex and creasing etc techniques, it is suitable for paper, cardboard, plastic file and so on. It can finish feeding, die cutting separating collecting work cycle automatically.

    Most of factory owners rather choose cardboard die cutting machine. They were attracted by economical, smart, easy to change plates and other features of this model. We will support installation and training for new customer for free (labor cost).


    Technical data

    ModelECOO TDS 750L
    Max. Sheet Size(mm)750x560
    Min. Sheet Size(mm)280x220
    Max. die cutting size(mm)700x500
    Max. stamping size(mm)700x500
    Height of cutting rules(mm)23.8
    Max. pressure(N)110x10⁴
    Stock rangeMin. Sheet 90g/m²; Cardboard 157-2000g/m²; E, B flute
    Max. machine speed(s/h)2500
    Max. stamping speed(s/h)2500
    The thickness of stamping plate(mm)3.5
    Foil advancing shafts2
    Feeding pile height(mm)800
    Delivery pile height(mm)160
    Electric heating system4 zones
    Min. foil width(mm)15
    Foil reel core(mm)25(1”) 76(3”)
    Rated power(kw)40
    Air supply0.8-1.0 MPa, ≥ 0.6mᶟ/min
    Overall dimension(mm)2600x1720x1975
