    Digital CTP Double Layer Positive Thermal Printing Plate

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : ECOO-ED
    Certification : ISO9000, CE
    Payment Terms : L/C, T/T
    Supply Ability : 2,000,000 Sqm Per Year
    Delivery Time : 30 Days
    Price : Negotiable
    • Product Details
    • Company Profile

    Digital CTP Double Layer Positive Thermal Printing Plate


    Digital CTP Double Layer Positive Thermal Printing Plate




    Application


    EcooGraphix Thermal Positive Double Layer CTP plate can be used for high grade commercial and newspaper printing. It can also be used for the UV ink printing with perfect performance.




    Specification


    Model
    ECOO-ED

    Plate Type
    Positive Thermal Digital Plate


    Application
    Commercial, newspaper and package print
    ing

    Substrate
    Electro chemically grained and Anodized lithographic aluminum


    Gauge
    0.15, 0.20, 0.25, 0.30, 0.40(mm)

    Maximum short grain width
    Maximum width 1280 mm


    Coating

    Two-layer system, IR sensitive, positive acting


    Length of Run
    Unbaked: 200,000 impressions
    UV Ink: 50,000 impressions


    Plate setters
    All thermal CTP machine

    Aluminum
    Standard 1050 Alloy


    Exposure energy
    110 - 130 mj/cm²

    Developing time
    25 - 30 sec


    Spectral Sensitivity
    780 - 850 nm

    Resolution
    1-99% @ 400LPI


    Developer
    ECOO DV-T Series Developer

    Processing temperature
    23ºC +/-2ºC


    Processing Speed
    0.80 - 1.20 m/min

    Safelight
    Daylight handling


    Shelf life
    12 months under recommended storage conditions

    Packaging
    Available in all standard formats, including bulk packaging options such as APL packaging


    Storage and handling
    Stored in a cool and dry environment, away from excessive cold, heat and humidity


    ModelECOO-ED
    Plate TypeThermal CTP Plate, Double Layer
    ApplicationHigh grade commercial and newspaper printing
    SubstrateElectro chemically Grained and Anodized lithographic Aluminum
    Gauge0.15, 0.20, 0.25, 0.30, 0.40(mm)
    Maximum short grain widthMaximum width 1280 mm
    CoatingTwo-layer system, IR sensitive, positive acting
    Length of Run

    Ordinary Ink: 100,000 to 200,000 impressions

    UV Ink: 30,000 to 50,000 impressions

    Plate settersAll thermal CTP machine
    AluminumStandard 1050 Alloy
    Exposure energy110– 130 mj/ m²
    Developing time25-30 sec
    Spectral Sensitivity800 – 850 nm – Peaks 830nm
    Resolution1-99% @ 200LPI
    Image ColorBlue
    DeveloperKodak Gold Star or our own developer
    Processing temperature23℃+/-2℃
    Processing Speed0.80 – 1.20 m/min
    safelightDaylight handling
    Shelf life12 months under recommended storage conditions
    PackagingAvailable in all standard formats, including bulk packaging options such as APL packaging
    Storage and handingStored in a cool and dry environment, away from excessive cold, heat and humidity



    Characteristic



    Benefits

    - Extensive adaptability, saving from waste during possible swift of consumables' supplying

    - Quick turn around time on press

    - Compatible with common developers

    - Premium quality of dot reproduction and super long run length




    Producing And Packaging


    From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.








    Certificates





    FAQ




    Q1: Can I get the sample ?


    A: We are very glad to provide some sample for you to test. We usually provide 5-15 pieces plates for free, but sincerely hope to get your kind support for the air courier freight. This cost can be returned to you in your first order.





    Q2: What is the cost for the CTP plate sample freight ?


    A: The air freight depends on the packing size and weight, and the delivery destination. Or you can arrange the pick-up service from your local agent.





    Q3: How long can the sample be ready ?


    A: It usually takes about 3 days to prepare the sample.





    Q4: Can I visit your factory ?


    A: You are warmly welcome to visit our factory! Our company is in Hangzhou city, which is about 1.5 hours by train from Shanghai.





    Q5: How many square meters CTP plates can feed one 20' container ?


    A: About 20000-25000sqm.





    Q6: Can I take my own brand and label on the packing ?


    A: Yes, we can provide the OEM with the customer's brand and label.
