    340mm A4 Paper Flute Laminator Machine 5m/Min Infrared Heating

    Ask Lasest Price
    Brand Name : Ecoographix
    Model Number : SRL 35A
    Certification : ISO9000, ISO20001, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 400 SET PER YEAR
    Delivery Time : 25 DAYS
    • Product Details
    • Company Profile

    340mm A4 Paper Flute Laminator Machine 5m/Min Infrared Heating

    1. Technical data


    Laminating Machine
    ModelSRL-35A
    Max. Laminating Width340mm
    Display67x67mm
    Maximum thickness2/7mm(according to custom needs)
    Laminating Speed0-5m/min
    Roller Diameter110mm
    Max. Heating Temperature160℃
    Preheat time15-20 minutes
    Type of paper120-350gsm
    Heating ModeInfrared heating
    Heating Power1500W
    Power SupplyAC100,110,220-240V / 50,60 Hz
    Motor Power180W
    Machine Dimension1150*630*1240mm
    WeightNet:220kgs Gross:260kgs

    340mm A4 Paper Flute Laminator Machine 5m/Min Infrared Heating


    2. Machine advantages


    1 Auto laminator, auto feed, auto cutting.
    2 Big mirror steel roller, diameter 110 mm
    3 Big pressure make the laminating brighter and more transparent.
    4 the intelligent temperature-controlling system is more precise and easily to operate.
    5 Frequent converter speed control, 180w AC motor, speed 0-5/min


    3. FAQ

    1. Our payment term?
    Normally, 30% deposit, 70% before shipping, or LC at sight.

    2. Our lead time?
    Usually 30-60 days, depend on machine design and setting.

    3. Our service policy?
    Our engineers are all can go to help the installation and provide the necessary training. The buyer should take the round air tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.

    4. Our other products?
    We also offer other postpress machines for package and label printing companies, like UV coating machine, laminating machine, window patching machine, carton inkjet printing machine and digital label printing machine, thermal paper slitting machine.


    4. Factory and certificate
