    900mm Unwinding Thermal Paper Slitter Rewinder 110M/Min

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : ECOO T-900
    Certification : ISO9000, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 Sets/Year
    Delivery Time : 45 Days
    • Product Details
    • Company Profile

    900mm Unwinding Thermal Paper Slitter Rewinder 110M/Min


    900mm Max. Unwinding Width Automatic Thermal Paper Slitter Rewinder







    °ω° Application Material °ω°

    All sorts of thermal paper, including fax paper, cash register paper, ATM paper, medical record paper, self-adhesive trade marks, films and so on for thermal paper slitter rewinder.






    °ω° Specification °ω°

    Model
    ECOO T-900


    Max. Unwinding Width
    900 mm


    Max. Unwinding Dia
    1000 mm

    Max. Rewinding Dia
    270 mm

    Min. Slitting Width
    25 mm

    Max. Machine Speed
    110 m/min

    Main Power
    2.95 kw

    Unwinding Shaft
    3''(76mm) air eapanding shaft

    Rewinding Shaft
    0.5'', 1'' or as your request

    Weigth
    1300 kg

    Demension
    2000*1700*1500 mm

    ModelECOO T-900
    Max. Unwinding Width900 mm
    Max. Unwinding Diameter1000 mm
    Max. Rewinding Diameter270 mm
    Min. Slitting Width25 mm
    Max. Machine Speed110 m/min
    Main Power2.95 Kw
    Unwinding Shaft3''(76mm) air eapanding shaft
    Rewinding Shaft0.5'', 1'' or as your request
    Weight1300 kgs
    Dimension2000*1700*1500 mm


    °ω° Detail °ω°


    Unwinding Section
    - Chain link automatic lift-up loading system

    - 3''(76mm) air expanding shaft
    - Floating roller constant tension
    - Two set sensors

    Slitting Section
    - Disc cutter
    - Disc cutter assembly adopt the cam self-locking
    - Cutter with adjustable and moveable blade base
    - Meter counter

    Rewinding Section
    - 0.5", 1", 1.5" or as your request
    - Center rewinding technology
    - Pressure roller
    - Automatic tucker

    Controlling Section
    - Siemens PLC & HMI from Germany
    - All the parameters are displayed on the monitor
    - Low voltage electrical appliances all from S c h n e i d e r

    Trimmed Waste Edge
    - Edge Waste Blower with Expulsion Tube

    Optional
    - Automatic Paper Core Loader
    - Automatic Cutting & Gluing Device
    - Automatic Roll Cut Off & Hammer Unit
    - Whole Packing Line for Thermal Rolls






    °ω° Producing And Packaging °ω°
    From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.













    °ω° Certification °ω°







    °ω° FAQ °ω°



    Q1: What are your main products ?

    A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.

    You can get the equipment and consumables all in one and no worry about the after-sales service from our company.




    Q2: Where is your factory ?

    A: Our CTP processor machine factory is in Shanghai, you are warmly welcome to visit our factory!




    Q3: How long is the lead time ?

    A: The lead time is normally 30 days. We can accelerate for emergency cases.




    Q4: Is there any certification for your machine ?

    A: Yes, all our machines have been certified by SGS and CE.




    Q5: How long is the warranty period ?

    A: EcooGraphix guarantees 1 year of warranty for laser head and spare parts.




    Q6: What is your normal payment term ?

    A: Normally, 30% TT deposit, 70% before shipping, or LC at sight.




    Q7: What about the installation and after-sales technician support ?

    A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.



    These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.




    Video ☞ https://youtu.be/4xqyJLVcko8
