    Overall Waterbase UV Varnish Coating Machine Paper Polishing 1200mm

    Ask Lasest Price
    Brand Name : ECOOGRAPHIX
    Model Number : ECOO JMS1200
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500SETS
    Delivery Time : 30DAYS
    • Product Details
    • Company Profile

    Overall Waterbase UV Varnish Coating Machine Paper Polishing 1200mm

    Paper Sheet Overall Coating UV Varnishing Machine 1200mm


    The Ecoo JMS1200 UV coating machine can do water base and overall UV varnish coating on printed matter and packaging products such as the books, posters, adhesive stickers etc. This machine is consist of Auto feed system, vanishing system, curing system and auto delivery system. It not only improves the quality of printed materials, but also increases the value of the products, makes more profits to printing companies. Because of the high speed and efficiency, it is getting very good reputations from clients all over the world.


    PRODUCT DESCRIPTION
    * The machine is suitable for using water-based glue, solvent-based glue, and thermal film.
    * Cold-water non-curling system: The paper will be non-curling after separated.
    * Low cost: Ceramic anilox roller coating, minimize gluing amount to 5g/sqm.
    * The heating energy cycle drying system makes the whole machine power consumption about 15kw/h.
    * High efficiency:The machine working speed reaches to 70m/min, 9000sheets/h.

    Remarks:
    Laminating speed depend on paper weight, film thickness and gule material quality.
    Subject to change without notice.
    Standard Configuration: Selectable Configuration:

    Auto Feeder

    Multifunctional Coating Unit

    UV Curing System

    Auto Delivery Unit

    Auto Control


    ModelEcoo JMS-1200Ecoo JMS-1450
    Max.sheet size1450x1200mm1650x1450mm
    MIN.sheet size330X406mm330X406mm
    Max.coating size1200mm1450mm
    Sheet thickness250-600gsm250-600gsm
    Coating registration accuracy±0.2mm±0.2mm
    Production speed25-80 m/min25-80 m/min
    Weight4300kg4800kg
    Dimension10480x2165x1580mm10780x2465x1580mm
    Power28KW34KW
    Remark: Production speed depending on sheet weight, size and quality
