Double-side Bookblock Offset Printer With Alcohol Or Water Dampening
∷ ∷ ∷ Standard Configurations
Mechanical double sheet inspection
Alloy steel gear
Precision tapered roller bearings for printing cylinders adopts
Grippers closed at cam's high point, open type impressing transfer
cylinders
Plate positioning system
Plate cylinder axial and circumferential adjustment
Fountain solution volume tracking system
Human machine interface operating system
Visual fault display system
Pneumatic control for ink rollers and dampening rollers
Splash lubrication system
Anti-static device
Available in water and alcohol dampening
∷ ∷ ∷ Specification
Model
ECOO HSS1040H/1040W
Max. Sheet Size
720*1040mm
Min. Sheet Size
710*1040mm
Min. Sheet Size
393*546mm
Machine Speed
10000sph
Paper Thickness
40-200g/m2
Plate Size
800*1055*0.3mm
Packing Size
735*1055*0.45-0.50mm
Blanket Size
960*1055*1.95mm
Max. Feeder Pile Height
1800mm
Max. Delivery Pile Height
950mm
Main Motor Power
11kw
Machine Size
6800*3800*2350mm
Weight
17500kg
| A1 Offset Printing Machine |
| Model | ECOO HSS 1040H/ HSS 1040W |
| Max. Sheet Size | 720*1040mm |
| Max. Printing Size | 710*1040mm |
| Min. Sheet Size | 393*546mm |
| Machine Speed | 10000sph |
| Paper Thickness | 40-200g/m2 |
| Plate Size | 800*1055*0.3mm |
| Packing Size | 735*1055*0.45-0.50mm |
| Blanket Size | 960*1055*1.95mm |
| Max. Feeder Pile Height | 1800mm |
| Max. Delivery Pile Height | 950mm |
| Main Motor Power | 11kw |
| Machine Size | 6800*3800*2350mm |
| Weight | 17500kg |
∷ ∷ ∷ Application
It is suitable for printing book blocks of books.
∷ ∷ ∷ Producing And Packaging
From producing to delivery, we make every details very carefully to
guarantee the good product quality and service to customers.
∷ ∷ ∷ Certificates
∷ ∷ ∷ FAQ
Q1: What are your main products ?
A: We Ecoographix is a specialized supplier of printing machines and
consumables. We cover both digital printing and offset printing,
including prepress, pressroom and post press, focusing on packaging
printing and book printing. We have hundreds of users all over the
world. We bring forward top quality of Chinese printing products to
meet diversified printing requirements.
Q2: Where is your factory ?
A: Our sale office is in Hangzhou, one hour by train away from
Shanghai. Our factories are in Shanghai, Wenzhou, Suzhou and
Nanyang.
Q3: What is the lead time ?
A: Usually 30 days, and we will try our best to meet your demands.
Q4: Can you also supply the software ?
A: Yes, we can provide the Workflow Brainnew and RIP Compose V12.
Q5: What about the installation and after-sales technician support
?
A: Our engineer can go to help the installation and provide the
necessary training. The buyer should take the round air plane
tickets, service charge and the local accommodation cost. Any
problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are
also many end users(printers) who have purchased the CTP products
from EcooGraphix China directly and EcooGraphix technical service
team support these installations remotely with regular onsite
visits.
These end users printers all run the CTP systems with full
satisfaction due to our robust quality, seamless remote service,
thorough training and maintenance. If you are a printer who is
considering purchasing directly from EcooGraphix China, there is no
hassle on installations, training and after sales service. We
guarantee your satisfaction.
