Medium/ High-speed Printing High Gloss Non Skin Offset Printing Ink
♈ Application
ECOO-INK-C printing ink is developed by the latest European
technology system. It is made from polymeric, high-soluble resin
and newly-invented paste pigment. This product is suitable for
printing packaging, advertisement, label, high-quality brochures
and decorative products on art paper, coated paper, offset paper,
cardboard, etc., especially suitable for medium and high-speed
printing.
♉ Specification
Type
ECOO-INK-C
Printing speed
12000rph-15000rph
Packing
1kg/2.5kg per tin, 12tins/6tins per carton
Shelf Life
3 years(from the production date); product against light and water
Appearance
Colored paste
| Type | ECOO-INK-C |
| Printing speed | 12000rph-15000rph |
| Packing | 1kg/2.5kg per tin, 12tins/6tins per carton |
| Shelf Life | 3 years(from the production date); Product against light and water |
| Appearance | Colored paste |
| ITEM/TYPE | TACK
VALUE | FLUIDITY
(mm) | PARTICLE
SIZE (μm) | GLOSS | SETTING
TIME (min) | DRYING
TIME (hr) | SKINNING TIME (hr) |
C
YELLOW | 8-9 | 39±1 | 12.5 | 85 | 4 | < 8-10 | > 30 |
C
MAGENTA | 8.5-9.5 | 40±1 | 12.5 | 75 | 4 | < 8-10 | > 30 |
C
CYAN | 8.5-9.5 | 39±1 | 12.5 | 75 | 4 | < 8-10 | > 30 |
C
BLACK | 9-10 | 38±1 | 12.5 | 80 | 4 | < 8-10 | > 30 |
| Tack Value | The value is measured in 1 minute by inkometer at 32ºC and 400rpm. |
| Set Time | Printing adapter, 157g art paper, the volume of ink-coating can be
up to 0.125cc |
| Condition of Test | Room temperature 25ºC, humidity 65%-75% |
| ITEM/TYPE | Light
Resistance | Heat
Resistance | Acid
Resistance | Alkaline
Resistance | Alcohol
Resistance | Soap
Resistance |
C
YELLOW | 3-4 | 5 | 5 | 4 | 4 | 4 |
C
MAGENTA | 3-4 | 5 | 5 | 5 | 4 | 5 |
C
CYAN | 6-7 | 5 | 5 | 5 | 5 | 5 |
C
BLACK | 6-7 | 5 | 5 | 5 | 5 | 5 |
| Light Fastness | 1-8 (weak-strong) |
| Others | 1-5 (weak-strong) |
♊ Features
♥ Environment friendly
♣ Anti-skinning performance
♦ Good water/ink balance
♠ Rich in printing layer
♥ Clear and complete in printing dots
♣ Quick-drying performance, quick setting, quick turn
♋ Tips
♥ Knowledge for sheet offset printing ink, web offset printing ink
and UV ink, digital printing ink.
Offset printing ink is used for lithographic offset presses. It is
thick and tacky. Offset printing ink consists 3 parts, the ink
vehicle, the pigment and additives. It can be used on web set
printing and sheet fed printing. Web offset printing ink tend to be
more fluid and have less tack than sheet offset lithographic ink.
UV ink usually means UV-curable ink. UV ink dries faster. So the
presses can run faster and there is led risk of offset. There is
led absorption of ink in the substrate, so colors are more vivid
and glossy. UV ink has lower emissions of organic solvents and it
is more suitable for printing on plastic and other non-porous
substrates.
Digital printing ink is transferred directly onto the surface,
rather than relying on aluminum plate and rubber blanket to
transfer an image. It is liquid ink and quick drying.
♣ What to do for specific color requirements from customers?
Customers sometimes need ink in specific color or ink with specific
characteristics, like drying speed, smell, resistance to fading,
gloss. Customers please send us detailed ink sample or pantone no#
so that we can produce carefully for you.
♦ How to storage offset printing ink?
The ideal process and storage temperature for offset inks is
between 18ºC-25ºC. If the offset inks are too high in viscosity due
to storing at low temperatures, problems may occur by insufficient
flow in the duct and picking at sensitive stocks. If the inks will
be processed in higher temperatures, so because of low viscosity
misting, ink/water problems or high sot gain may occur.
The ink cans have to be stored vertically standing under exclusion
of daylight.
♎ Producing And Packaging
From producing to delivery, we make every details very carefully to
guarantee the good product quality and service to customers.
♏ Certificates
♐ FAQ
Q1: What to do for specific color requirements from our company ?
A: We offer customers inks in specific color or ink with specific
characteristics sometimes, like drying speed, smell, resistance to
fading, gloss. Please send us detailed ink sample or pantone no# so
that we can produce carefully for you.
Q2: How to storage offset printing ink ?
A: The ideal process and storage temperature for offset inks is
between 18ºC-25ºC. If the offset inks are too high in viscosity due
to storing at low temperatures problems may occur by insufficient
flow in the duct and picking at sensitive stocks. If the inks will
be processed in higher temperatures, so because of low viscosity
misting, ink/water problems or high sot gain may occur.
The ink cans have to be stored vertically standing under exclusion
of daylight.
Q3: Can I get the sample ?
A: We are very glad to provide some free sample for you to test. We
usually provide 1 set ink 4kg(1kg/can) for free, but sincerely hope
to get your kind support for the air courier freight. This cost can be returned to you in your first order.
Q4: Can I visit your factory ?
A: You are warmly welcome to visit our factory! Our company is in
Hangzhou city, which is about 1.5 hours by train from Shanghai.
Q5: Can I take my own brand and label on the packing ?
A: Yes, we can provide the OEM with the customer's brand and label.
