    10-160um Label Foil Stamping And Varnish Machine

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : Ecoospark
    Certification : CE, ISO900
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 100SETS/YEAR
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    10-160um Label Foil Stamping And Varnish Machine

    10-160um Label Foil Stamping And Varnish Machine


    (For Cold Foil Stamping, 3D Embossing, Spot Varnishing)


    Product Description


    EcooGraphix's newly developed EcooSpark digital printing machine realizes digitalsynergistic processes such as digital varnishing, 3D crystal bright, partial glazing, cold foil, stamping, embossing and etc.,without the need for plate making. It can reduce costsand instantly realize unique visual effects of printing. This is a digital post-press equipment that creates new profit points for users, and is a digital efficiency-enhancing printing machine.
    Applications: Wine Labels, Cosmetic Labels, Luxury labels and so on:
    Specification

    ModelDigispark
    Printing TechnologyUV Piezo DoD-inkjet
    ResolutionUp to 1080*360 dpi
    Printing speed6m/min - 30m/min(depend on polymer layer thickness)
    Variable Image systemPDF, optimized PDF, Optional barcode system
    Supported image standardsPDF,PDF/VT,TIFF, JPEG, BMP & other data base files
    SubstratesOffset, Digital, Plastics, Laminated and coated substrates
    Printing image width280mm (extendable to 320 mm)
    PolymerWB-DS-Clear Polymer
    Polymer layer thicknessFrom 10 up to 180 microns
    Ink curingInter UV-LED Pre-curing/Full curing by UV-LED
    Unwinder diameterMax. 700mm, Core 76mm
    Rewinder diameterMax. 700mm, Core 76mm
    Substrates thickness30-400 micro
    Substrates width330mm
    Press with Foil station dimensions (LxHxW)3500mmx1900mmx1800mm
    Operating environmentTemperature: 15ºC-30ºC, Humidity: 40%-80% relative humidity
    Electrical requirementsVoltage: 3x380, ±5% 3 phases +G+N Frequency: 50/60 Hz
    Current: Avg. 25 Amps in Production
    Weight2800kg
    Features:
    Sturdy structure (double wall panel design)
    Thick and thin materials, stability, mature platform
    High stability
    Good material applicability
    No heating required
    LED UV+water cooling roller
    Suitable for ordinary cold foil

    High quality-details, sharp edges:
    Less heat, higher stability
    Patented technology-better detail performance
    Multi-process completed at one time
    Customizable
    More Details


    EcooSpark Workflow:


    EcooSpark advantages:


    Effect of different thickness of foiling line on BOPPPPPETArt Coated paper:


    Effect of different type of fonts:

    Producing And Packaging

    FAQ


    1. What are the postpress effects achieved by this machine?
    Cold foil stamping, varnishing, 3D shining and embossing.


    2. Can this model do color printing?
    No. If you need a hybrid label printing machine which can do both printing and postpress printing, you can consider our other models. Please consult our sales.

    3. How about the lead time and payment term?
    We need 45 days to produce this machine. Normally our payment term is 30% deposit and 60% balance before shipment and 10% after installation.

    4. How about the installation and operation training?
    Our senior will fly to your location to do installation and training. It takes about 2 weeks. The service is free of charge but we will need the buyer to take the round trip freight and local hotel and meal cost.

    5. Can you do the sample as we required?
    Yes, we can sample your artwork on your specified printing substrate and then courier to you. and also shoted the printing procedure for your reference.

    6. Is the machine printing white?
    No. This is not a color printing machine. It is more like a varnish-jet postpress machine.

    7. Is the machine all digital? What are the other similar machines in the markets?
    Yes, all postpress procedures are digital, without any blanket or flexo plate. Just similar to Domino, HP, Epson and screen related products. But much more affordable.
