EcooSpark UV Piezo LED Curing Digital Label Printing Machine Efficiency Enhancing

Hangzhou Ecoographix Digital Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap EcooSpark UV Piezo LED Curing Digital Label Printing Machine Efficiency Enhancing from wholesalers

    Buy cheap EcooSpark UV Piezo LED Curing Digital Label Printing Machine Efficiency Enhancing from wholesalers
    • Buy cheap EcooSpark UV Piezo LED Curing Digital Label Printing Machine Efficiency Enhancing from wholesalers

    EcooSpark UV Piezo LED Curing Digital Label Printing Machine Efficiency Enhancing

    Ask Lasest Price
    Brand Name : EcooGraphix
    Model Number : EcooSpark
    Certification : ISO9000, CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 Sets/Year
    Delivery Time : 45 Days
    • Product Details
    • Company Profile

    EcooSpark UV Piezo LED Curing Digital Label Printing Machine Efficiency Enhancing


    UV-LED Curing Digital Label Efficiency-enhancing Machine





    Introduction

    EcooGraphix's newly developed EcooSpark digital printing machine revolutionizes the post-press process by enabling advanced digital techniques such as digital varnish, 3D crystal bright effects, partial glazing, cold stamping, and embossing, all without the need for traditional plate making. This cutting-edge technology significantly reduces production costs while instantly delivering unique visual effects, enhancing the overall quality and appeal of printed materials.

    The EcooSpark machine is not just a digital printing device; it's a powerful tool for creating new profit opportunities. By integrating these digital synergistic processes, it offers users the ability to produce high-quality, eye-catching prints efficiently and cost-effectively. This makes the EcooSpark a key asset for businesses looking to improve their post-press operations and boost their competitive edge in the market. Its innovative features ensure that users can achieve exceptional results, making it a digital efficiency-enhancing printing machine that stands out in the industry.



    Specification


    EcooSpark Digital Foil Stamping And Varnishing Enhancing Machine

    Model
    EcooSpark

    Printing Technology
    UV Piezo DoD-inkjet

    Resolution
    360*360 dpi, up to 1440*360 dpi

    Printing speed
    6m/min - 50m/min(depend on polymer layer thickness)

    Variable Image system
    PDF, Optimized PDF, Optional barcode system

    Supported image standards
    PDF, PDF/VT, TIFF, JPEG, BMP & other data base files

    Substrates
    Offset, Digital, Plastics, Laminated and Coated Substrates

    Printing image width
    288mm(extendable to 330 mm)

    Polymer
    WB-DS-Clear Polymer

    Polymer layer thickness
    From 10 up to 250 microns

    Ink curing
    Inter UV-LED Pre-curing/ Full curing by UV-LED

    Unwinder diameter
    Max. 700mm, Core 76mm

    Rewinder diameter
    Max. 700mm, Core 76mm

    Substrates thickness
    30-400 micro

    Substrates width
    Max. 330mm

    Press with Foil station
    Machine dimensions(LxHxW): 3500mm x 1900mm x 1800mm

    Operating environment
    Temperature: 15ºC-30ºC, Humidity: 40%-80% relative humidity

    Electrical requirements
    Voltage: 3x380, ±5% 3 phases +G+N; Frequency: 50/60 Hz;
    Current: Avg. 58.6 Amps 23KW

    Weight
    2800kg
    EcooSpark Digital Foil Stamping And Varnishing Enhancing Machine
    ModelEcooSpark
    Printing technologyUV Piezo DoD-inkjet
    Resolution360*360 dpi, up to 1440*360 dpi
    Printing speed6m/min - 50m/min(depend on polymer layer thickness)
    Variable image systemPDF, Optimized PDF, Optional barcode system
    Supported image standardsPDF, PDF/VT, TIFF, JPEG, BMP & other data base files
    SubstratesOffset, Digital, Plastics, Laminated and Coated Substrates
    Printing image width288mm(extendable to 330 mm)
    PolymerWB-DS-Clear Polymer
    Polymer layer thicknessFrom 10 up to 250 microns
    Ink curingInter UV-LED Pre-curing/ Full curing by UV-LED
    Unwinder diameterMax. 700mm, Core 76mm
    Rewinder diameterMax. 700mm, Core 76mm
    Substrates thickness30-400 micro
    Substrates widthMax. 330mm
    Press with foil stationMachine dimensions(LxHxW): 3500mm x 1900mm x 1800mm
    Operating environmentTemperature: 15ºC-30ºC, Humidity: 40%-80% relative humidity
    Electrical requirements

    Voltage: 3x380, ±5% 3 phases +G+N; Frequency: 50/60 Hz
    Current: Avg.
    58.6 Amps 23KW

    Weight2800kg



    Applications






    Advantages





    Workflow





    Producing And Packaging

    From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.




    Certificates





    FAQ

    Q1: What are your main products?

    A: Our main products include the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment, and more. We provide a comprehensive range of equipment and consumables, ensuring seamless after-sales service from our company.


    Q2: Where is your factory located?


    A: Our CTP Processor machine factory is located in Shanghai. We warmly welcome you to visit our factory!


    Q3: What is the lead time for your products?


    A: The standard lead time is 30 days. However, we can expedite the process for urgent orders.


    Q4: Are your machines certified?


    A: Yes, all our machines have been certified by SGS and CE.


    Q5: What is the warranty period for your machines?


    A: EcooGraphix offers a 1-year warranty for spare parts (including print heads).


    Q6: What are your payment terms?


    A: Our standard payment terms are 30% TT deposit and 70% balance before shipping, or LC at sight.


    Q7: What about installation and after-sales technical support?


    A: We provide comprehensive installation support and necessary training. Our engineers can travel to your location, with the buyer covering the round-trip airfare, service charges, and local accommodation costs. We offer 24/7 support for any issues or questions.
    Our extensive global installations include many end-users who directly purchase CTP products from EcooGraphix China. Our technical service team supports these installations remotely with regular onsite visits. These end-users consistently report high satisfaction due to our robust quality, seamless remote service, thorough training, and maintenance. If you are considering purchasing directly from EcooGraphix China, we ensure hassle-free installations, training, and after-sales service, guaranteeing your satisfaction.


    For more information, please watch our video: Watch here

    Visit our website: www.ecoographix.com
