Solvent Resistent Double Layer Thermal CTP Plate For Printing
Production Despription
Double Layer, UV Ink capable, Solvent Resistent--ECOO-TSR
Detail Photos
Product Paremeters
| Model | ECOO-TSR |
| Plate Type | Positive Thermal Digital Plate |
| Application | Commercial, newspaper and packaging print |
| Substrate | Electro chemically Grained and Anodized lithographic Aluminum |
| Gauge | 0.15, 0.20, 0.24, 0.30, 0.40(mm) |
| Maximum short grain width | Maximum width 1280 mm |
| Coating | Blue |
| Length of Run | Unbaked: 400,000 impressions UV Ink : 100,000 impressions |
| Plate setters | All thermal CTP machine |
| Aluminum | Standard 1050 Alloy |
| Exposure energy | 120 – 150 mj/ m² |
| Developing time | 25-30 sec |
| Spectral Sensitivity | 780 – 850 nm |
| Resolution | 1-99% @ 400LPI |
| Developer | Ecoo DV-T Series Developer |
| Processing temperature | 23℃+/-2℃ |
| Processing Speed | 0.80 – 1.20 m/min |
| safelight | Daylight handling |
| Shelf life | 12 months under recommended storage conditions |
| Packaging | Available in all standard formats, including bulk packaging options
such as APL packaging |
| Storage and handing | Stored in a cool and dry environment, away from excessive cold,
heat and humidity |
Certifications
Our Advantages
Features
High-quality aluminum substrate and unique-grain processing
technology. The substrate grain is uniform fine, which ensures the
exact dot reproduction and excellent printing adaptability of the
printing plate.
The professional formula design with infrared laser sensitive
phase-change layer ensures that the plate can be put on press
directly after exposure.
High sensitivity, wide tolerance, screen dots with margin sharpness
Excellent printability, fast-inking balance, suitable for
high-grade commercial and packaging printing.
Compatible with various dominant thermal platesetters in the
market, suitable for manual and automatic loading system.
Bright room operation in which people can operate safely under
fluorescent lamp.
Stable quality.
A variety of the plates provided with thickness from 0.15mm to
0.40mm.
Application
Suitable for sheet-fed offset press or high speed rotary offset
press.
Run length: 100000 impressions
Suitable for different types of traditional inks and fountain
solutions, including alcohol's substitutes as fountain solutions.
Unsuitable to improve run length by baking plates.
Our Clients
We have a large and diverse customer base across the globe, with
clients in many different countries and regions. Our extensive
experience working internationally allows us to cater to various
needs and provide tailored solutions to businesses worldwide.
FAQ
1. Q: How long is the lead time?
A: The lead time is normally 45 days.
2. Q: Do you offer free plate samples?
A: Yes, we offer free testing samples maximum 12 pcs for each size
but with delivery fee to collect.
3. Q: How do you guarantee stable quality?
A: There are 3 inpecting procedures: 1, automatic on-line 24h
scanning detector; 2, random sampling per 15 mins at the producing
line; 3, manually full inspection before packing. The production is
mature. It is not a new product to us.
4. Q: Do you have accompanying plate making products to enable
one-stand easy purchase for some end users?
A: Yes. CTP machine, processors, violet plate, CTP-CTCP plate,
chemistry(fountain solution, roller wash, etc.) are all available
to make your purchase more easily.
5. Q: Payment term?
A: Normally, 30% T/T deposit, 70% T/T before shipping, or LC at sight.
6. Q: Is refrigerating container necessary for shipment?
A: No. The plate is relatively stable and mature. So normal
container is enough unless some ertreme hot situations.
